9007A Osisense Heavy Duty Rotary Limit Switch Head, Lever, For Use With 9007C Series Limit Switch

MFR:
Telemecanique Sensors
MFR #:
9007A
UPC:
785901500889
Item #:
80112

Availability

Location Available Qty
Available 4
$110.67 each

These industrial heavy duty limit switches are applied in almost any environments. This replacement lever arm rotary limit switch head with low differential can be used on any of the 9007C bodies types. The limit switch head will actuate the snap action contacts when the lever arm in operated in the clockwise or counterclockwise direction. This limit switch head is NEMA 1, 2 4, 6, 6P, 12 and 13 rated when properly assembled to a 9007C body. It is also rated IP67. Limit switch head is UL listed and CSA certified. It weighs 0.19kg. It is compatible with 9007C limit switches. The 9007 series limit switches are designed to withstand harsh industrial environments and are available in a wide range of options.

Manuals and Documentation
Catalog Number 9007A
Manufacturer Telemecanique Sensors
Brand Telemecanique
Warranty Description Contractual Warranty:18 months
Country of Origin Mexico
Made in USA No
Action Lateral approach, 1 or 2 programmable direction;CW and CCW;from left and right
Actuator Spring return without operating lever zinc low differential
Application 9007C
Standard UL LISTED FILE NUMBER E42259 CCN NKCR - CSA CERTIFIED FILE NUMBER LR25490 CLASS 3211-03 - CE MARKED
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=373295&lang=en-us
UPC 785901500889
GTIN 00785901500889
Item Type Limit switch head
Environmental Conditions STANDARD ENVIRONMENT
Operating Temperature -20-185 A Degrees F
