Discontinued
5XP-A AC/DC Compact Digital Multimeter With VolTect, 2 to 600 VAC/VDC, 200 mVAC/mVDC, 200 uA, 2 to 200 mA, 200 Ohm/2 to 200 kOhm/2 to 20 MOhm, 3-1/2 Digits 1999 Counts LCD Display
- MFR:
- Fluke
- MFR #:
- 5XP-A
- UPC:
- 095969365444
- Item #:
- 86138
Discontinued
5XP-A AC/DC Compact Digital Multimeter With VolTect, 2 to 600 VAC/VDC, 200 mVAC/mVDC, 200 uA, 2 to 200 mA, 200 Ohm/2 to 200 kOhm/2 to 20 MOhm, 3-1/2 Digits 1999 Counts LCD Display
- MFR #:
- 5XP-A
- UPC:
- 095969365444
- Item #:
- 86138
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
The Amprobe® 5XP-A digital multimeter provides superior features and accuracy in a smaller form factor. The 5XP-A has unique features such as VolTect™ non-contact voltage detection and our exclusive Magne-Grip™ holster that frees both hands for work. The 5XP-A is the perfect choice for residential, commercial and general troubleshooting applications.
Manuals and Documentation
Features
- 27 ranges/10 functions
- Battery load test with 1.5 VDC and 9 VDC capabilities
- Data hold
- Maximum/minimum record maximum and minimum values
- VolTect™ non-contact voltage (NVC) detection
- Low battery indication
- +/-1.5% RDG + 1 digit DC current accuracy
- +/-2% RDG + 5 digits AC current accuracy
- +/-1% RDG + 4 digits at 200 Ohm and 2 to 200 kOhm, +/-1.5% RDG + 4 digits at 2 MOhm, +/-2% RDG + 5 digits at 20 MOhm resistance accuracy
| Manufacturer Part Number | 5XP-A |
| Brand | Amprobe® |
| Manufacturer | Fluke |
| UPC | 095969365444 |
| Country Of Origin | TW |
| Amperage Rating | 200 uA/2 to 200 mA |
| Battery Type | 9 VDC Alkaline |
| Dimensions | 6.1 in L x 2.8 in W x 1.3 in H |
| Display Type | 3-1/2 Digits 1999 Counts LCD |
| Temperature Rating | 0 to 50 deg C |
| Type | AC/DC Compact |
| Voltage Rating | 2 to 600 V, 200 mV AC/DC |
| Alternative Part Number | 2727851 |
| Manufacturer Item Status | Active |
| Country | USA |
| Warranty | 1 year |
| Standards Approvals | RoHS Compliant | cUL Listed | CE Marked | cCSAus Certified | C-Tick N10140 | NEDA 1604 | JIS 006P | IEC 6F22 |
| Application | Residential, Commercial and General Troubleshooting Applications |
| Includes | Test Leads, Carrying Case, Magne-Grip™ Holder with Hanging Strap and User Manual |
| Accuracy | +/-1.5% RDG + 5 Digits for V AC, +/-1% RDG + 1 Digit for V DC |
| Diode Test | Yes |
| Peak Hold | No |
| Resistance | 200 Ohm/2 to 200 kOhm/2 to 20 MOhm |
| Resolution | 100 uV |
| Safety Rating | CAT III 300 V, CAT II 600 V, CAT I 1000 V |
