LC1D2586F7 TeSys D Contactor With Front Cover, 110 V AC V Coil, 40 A, 1NO-1NC/2NO-2NC Contact, 4 Poles
- MFR:
- Schneider Electric
- MFR #:
- LC1D2586F7
- Item #:
- 979680
LC1D2586F7 TeSys D Contactor With Front Cover, 110 V AC V Coil, 40 A, 1NO-1NC/2NO-2NC Contact, 4 Poles
- MFR #:
- LC1D2586F7
- Item #:
- 979680
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
TeSys D contactors have been designed for perfect integration into control systems. They can be used to create motor starters for almost any type of application. TeSys D contactors are available in 13 contactor ratings for inductive motor applications up to 150 full-load amps and resistive loads up to 200 amps. This 4 pole IEC contactor can be mounted on DIN rail or mounted directly to a panel. Contactor has two normally open and two normally closed power contacts. Power contacts have a 40A resistive load rating. Contactor is supplied with a 110 VAC 50/60 Hz coil. Contactor has one normally open and one normally closed auxiliary contact built-in as standard. The NC contact is mirror certified. Ring-lug screw terminals are used for load and auxiliary connections. An extensive line of accessories makes it easy to meet the requirements of most applications. The contactor is 4.13 inches tall, 1.77 inches wide and 3.90 inches deep. It weighs 0.94 lbs. Contactor is certified to UL, CSA, IEC, CCC, EAC and Marine standards. Contactor also meets the requirements of RoHS/REACh making it a Green Premium product.
Manuals and Documentation
| Catalog Number | LC1D2586F7 |
| Manufacturer | Schneider Electric |
| Brand | SCHNEIDER ELECTRIC |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | France |
| Made in USA | No |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=615506&lang=en-us |
| GTIN | 03389110293104 |
