HBL504NM Grounding Standard Watertight Screw Mount Shore Power Inlet, 125/250 V AC, 50 A, 3 Poles, 4 Wires, White
- MFR:
- Hubbell Wiring Device-Kellems
- MFR #:
- HBL504NM
- UPC:
- 783585519470
- Item #:
- 96672
HBL504NM Grounding Standard Watertight Screw Mount Shore Power Inlet, 125/250 V AC, 50 A, 3 Poles, 4 Wires, White
- MFR #:
- HBL504NM
- UPC:
- 783585519470
- Item #:
- 96672
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$263.82
each
Manuals and Documentation
| Catalog Number | HBL504NM |
| Manufacturer | Hubbell Wiring Device-Kellems |
| Brand | Hubbell Wiring Device - Kellems |
| Country of Origin | Puerto Rico |
| Made in USA | No |
| Amperage Rating | 50 |
| Application | Marine Wiring Devices |
| Color | White |
| Connection | Pressure Screw Terminals |
| Insulation | Insulated Body |
| Material | Thermoplastic |
| Mounting | Screw |
| Number of Poles | 3 |
| Number of Wires | 4-Wire Grounding |
| Phase | 1 |
| Special Features | Non-Metallic Housing |
| Standard | UL Listed |
| UPC | 783585519470 |
| GTIN | 00783585519470 |
| Item Type | Hull Mount Single Inlet |
| Size | Standard Sized Product |
| Environmental Conditions | Watertight |
| Temperature Rating | Maximum Continuous: 75 Degrees C; Minimum Continuous: -40 Degrees C w/o impact |
| Voltage Rating | 125/250 |
| Wattage | 12,500 |
| Wire Size | #6 AWG |
