GFSMCB120240503P GFSMCB Heavy Duty Split Phase GFCI Sensing Module Standard Circuit Breaker, 120/240 V AC, 50 A, 10 kA Interrupt, 3 Poles, Thermal Magnetic Trip
- MFR:
- Hubbell Wiring Device-Kellems
- MFR #:
- GFSMCB120240503P
- UPC:
- 783585692579
- Item #:
- 950094
GFSMCB120240503P GFSMCB Heavy Duty Split Phase GFCI Sensing Module Standard Circuit Breaker, 120/240 V AC, 50 A, 10 kA Interrupt, 3 Poles, Thermal Magnetic Trip
- MFR #:
- GFSMCB120240503P
- UPC:
- 783585692579
- Item #:
- 950094
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
| Catalog Number | GFSMCB120240503P |
| Manufacturer | Hubbell Wiring Device-Kellems |
| Brand | Hubbell Wiring Device - Kellems |
| Country of Origin | Mexico |
| Made in USA | No |
| Actuator | Toggle |
| Application | Heavy Duty Industrial Commercial |
| Connection | Terminal Screws |
| Current Rating | 50 AMPS |
| Frame | Standard |
| Frequency Rating | 60 HZ |
| Interrupt Rating | 10,000 AMPS |
| Load Rating | 80% of Full Rating Continuous A |
| Material | Composite |
| Number of Poles | 3 |
| Special Features | Standard Product |
| Standard | UL 2201 and UL 943 |
| UPC | 783585692579 |
| GTIN | 00783585692579 |
| Item Type | Circuit Breaker |
| Length | 3.00" |
| Width | 2.23 |
| Width UOM | Inch |
| Height | 3 |
| Height UOM | Inch |
| Environmental Conditions | NEMA 4X with Supplied Gasket |
| Operating Temperature | Max Continuous- 75 Degrees C, Minimum- -40 Without Impact |
| Trip Range | 4 to 6 mA in |
| Trip Type | .025 Seconds |
| Voltage Rating | 120/240 |
