SSP3A250BDR Zelio 3-Phase Random Switching Solid State Relay, 50 A, 1NO 1 Form A SPST Contact, 4 to 32 V DC V Coil
- MFR:
- Schneider Electric
- MFR #:
- SSP3A250BDR
- Item #:
- 913651
SSP3A250BDR Zelio 3-Phase Random Switching Solid State Relay, 50 A, 1NO 1 Form A SPST Contact, 4 to 32 V DC V Coil
- MFR #:
- SSP3A250BDR
- Item #:
- 913651
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$210.33
each
SSP panel mount relay is part of the Harmony Solid sate relays range. This three-phase panel mount static relay accepts wiring with either bare cable, crimped cable ends, fork lugs or ring lugs Its rated current is 50A, is controlled withA 4V to 32V DC circuit, has a rated load voltage of 48V to 530V AC output. 0 It has a visual indicator showing the status of its input and a alarm output enabling a quick response to unexpected events 0
Manuals and Documentation
| Catalog Number | SSP3A250BDR |
| Manufacturer | Schneider Electric |
| Brand | SCHNEIDER ELECTRIC |
| Country of Origin | Mexico |
| Made in USA | No |
| Connection | Screw terminals 1 x 0.2...1 x 2.5 mm², AWG 24...AWG 14) input;screw terminals 1 x 1.5...1 x 10 mm², AWG 16...AWG 8) output |
| Mounting | Panel Mount |
| Phase | 3 |
| Response Time | 8.33 ms (turn-off);0.1 ms (turn-on) |
| Special Features | LED, green input |
| Standard | IP20 |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=267287201&lang=en-us |
| GTIN | 03606480579943 |
| Item Type | Solid state relay up to 50 A |
