9F60FPK003 Type EJO1 1-Barrel Medium Voltage Power Distribution Fuse, 3 A, 38 kV AC, 26 kA, Class E, Ferrule Body
- MFR:
- Mersen
- MFR #:
- 9F60FPK003
- UPC:
- 782001397265
- Item #:
- 911533
9F60FPK003 Type EJO1 1-Barrel Medium Voltage Power Distribution Fuse, 3 A, 38 kV AC, 26 kA, Class E, Ferrule Body
- MFR #:
- 9F60FPK003
- UPC:
- 782001397265
- Item #:
- 911533
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
Medium Voltage E-Rated Fuse 38000VAC 3A Ferrule, Series: FPK Visual Indicator
Manuals and Documentation
| Catalog Number | 9F60FPK003 |
| Manufacturer | Mersen |
| Brand | Mersen |
| Country of Origin | Mexico |
| Made in USA | No |
| Amperage Rating | 3 |
| Application | Protection for 26 kV to 38 kV transformers or distribution systems. |
| Connection | Ferrule |
| Interrupt Rating | 26 KA |
| Mounting | Clip |
| Special Features | Amp-Trap CS-3 and 9F62 series are UL listed for compatibility with UL listed equipment Ferrule mounting for standard clips and interchangeability with other brands of fuses Current-limiting for superior equipment protection Non-venting for silent operation Metal embossed catalog number and manufacturing date for lasting identification Outdoor usage for the 9F62 and 9F60 type EJO Blown-fuse indicator to give positive identification of open fuse: Amp-Trap: 2" Barrel 1 lb tripped force - 0.19 Inch Amp-Trap: 3" Barrel 2 lb tripped force - 0.50 Inch 9F60/9F62: 0.125 lb tripped force – 0.20 Inch |
| Standard | Some UL listed to standard File E143362 |
| UPC | 782001397265 |
| GTIN | 00782001397265 |
| Item Type | General Purpose Ferrule Mount Fuses for Transformer Protection |
| Size | 30.81 x 3 |
| Type of Indicators | Visual Indicator |
| Voltage Rating | 38000 |
