Leviton®

2823 3-Phase Grounding Cable Mount Locking Connector, 277/480 V AC, 30 A, 4 Poles, 5 Wires, Black/White

MFR:
Leviton
MFR #:
2823
UPC:
078477808610
Item #:
9094

Availability

Location Available Qty
Available Available to Order
$151.95 each

Leviton® Dustguard® line of industrial grade plugs and connectors feature rugged construction that resists impact, sunlight, chemicals and rough use. All contacts are solid 1-piece construction for superior conductivity. They are engineered to IP44 splashproof and dust tight standards. The ergonomic, fluted body design with radial gripping edge is ideal for gripping and pulling. The unique cord clamp accepts a wide range of cord sizes, providing a secure grip without damaging the cord. And, they are backed by a limited lifetime warranty.

Manuals and Documentation
Manufacturer Part Number 2823
Brand Leviton®
Manufacturer Leviton
UPC 078477808610
Country Of Origin MX
Amperage Rating 30 A
Color Black/White
Dimensions 2.22 in Dia x 3.78 in L
Horsepower 10 hp
Material Nylon
Temperature Rating -40 to 60 deg C
Type 3-Phase Grounding Cable Mount
Voltage Rating 277/480 V AC
Alternative Part Number 7332024
Manufacturer Item Status Active
Country USA/Canada
Standards Approvals ANSI C73 | CSA C22.2 No.42 File No. LR406 | NOM 057 | NEMA WD1/WD6 | UL 498 File No. E13393 | Federal Specification WC596 | UL94 V-2 Flammability Rating
Application Industrial Applications
Cord Diameter 0.595 to 1.15 in
Grade Industrial
Nema Rating NEMA L22-30R
Number Of Poles 4
Number Of Wires 5
Terminal Type Screw
