LC1K1210G7 TeSys K K-Line IEC Contactor, 120/690 V AC V Coil, 12/16/20 A, 3NO Contact, 3 Poles
- MFR:
- Schneider Electric
- MFR #:
- LC1K1210G7
- Item #:
- 90563
LC1K1210G7 TeSys K K-Line IEC Contactor, 120/690 V AC V Coil, 12/16/20 A, 3NO Contact, 3 Poles
- MFR #:
- LC1K1210G7
- Item #:
- 90563
Availability
| Location | Available Qty |
|---|---|
| Available | 11 ea |
LC1K1210G7 is a compact 3-pole TeSys K contactor from Schneider Electric for motor applications. Rated 12A AC-3 5.5kW@400V, it includes a 120V 50/60Hz AC coil and 1NO auxiliary contact. LC1K1210G7 is a 3-pole TeSys K contactor from Schneider Electric for simple motor applications rated up to 5.5kW@400V. Very compact, DIN-rail compatible, with connections by screw clamp terminals, it includes a 120V 50/60Hz AC coil and 1NO built-in auxiliary contact. Available worldwide, it complies with multi-standards (IEC, UL, CSA, CCC, EAC, Marine). Very compact, 45mm wide, for DIN-rail and panel mounting. Provides a control circuit compatible with 50Hz and 60Hz supplies and 1NO built-in auxiliary contact. Optimized for simple power applications. Can be completed with auxiliary contact blocks (LA1K, LA2K) and thermal relays (LR2K).
Manuals and Documentation
| Catalog Number | LC1K1210G7 |
| Manufacturer | Schneider Electric |
| Brand | SCHNEIDER ELECTRIC |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Mexico |
| Made in USA | No |
| Application | Motor control;resistive load |
| Coil Voltage | 120 V AC 50/60 Hz |
| Contact Configuration | 1 NO |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=623436&lang=en-us |
| GTIN | 03389110603828 |
| Item Type | Contactor;LC1K |
