U1254-RXL-KK-K1-SLVG 4 Term, Ringless, Large Hub Opening Adapt to Small, Horn Bypass, 4 Position, Single Connector, 6-350 kcmil
- MFR:
- Milbank
- MFR #:
- U1254-RXL-KK-K1-SLVG
- UPC:
- 784572588363
- Item #:
- 898967
U1254-RXL-KK-K1-SLVG 4 Term, Ringless, Large Hub Opening Adapt to Small, Horn Bypass, 4 Position, Single Connector, 6-350 kcmil
- MFR #:
- U1254-RXL-KK-K1-SLVG
- UPC:
- 784572588363
- Item #:
- 898967
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$1,668.92
each
4 TERM RNGLS LRG HUB OPEN ADAPT TO SML HUB OPEN HRN BYPS 4 POS SGL CONN 6-350kcmil BUSS INS SLEEVE
Manuals and Documentation
| Catalog Number | U1254-RXL-KK-K1-SLVG |
| Manufacturer | Milbank |
| Brand | Milbank |
| Country of Origin | United States |
| Made in USA | Yes |
| Amperage Rating | 200 |
| Application | Meter Socket |
| Bypass Type | Horn |
| Cable Entry | Overhead or Underground with Center Wireway |
| Enclosure | G90 Galvanized Steel with Powder Coat Finish |
| Frequency Rating | 60 Hertz |
| Insulation | Glass Polyester |
| Material | G90 Galvanized Steel With Powder Coat Finish |
| Mounting | Surface Mount |
| Number of Jaws | 4 Terminal |
| Phase | 1 |
| Standard | UL Listed;Type 3R |
| UPC | 784572588363 |
| GTIN | 00784572588363 |
| Item Type | Ringless Meter Socket |
| Length | 5.125 |
| Length UOM | Inch |
| Width | 42.688 |
| Width UOM | Inch |
| Height | 16 |
| Height UOM | Inch |
| Size | 5.125L x 42.688W x 16H |
| Terminals | Single Mechanical |
| Voltage Rating | 300 Volts Alternating Current |
