Fuse Block 600VAC 600VDC Class G 15A 2-Pole Pressure Plate with Reinforced Clip
Manuals and Documentation
| Catalog Number | 40122G |
| Manufacturer | Mersen |
| Brand | Mersen |
| Country of Origin | Mexico |
| Made in USA | No |
| Amperage Rating | 15 |
| Connection | Pressure Plate with Reinforced Clip |
| Material | Glass Filled Polycarbonate |
| Mounting | Din Rail |
| Number of Poles | 2 |
| Special Features | Unique integral DIN-rail adapters for 15, 20 & 30A blocks Unique adder-block design (all ampere ratings) for design flexibility Spring reinforcing standard for 60A clips Features high conductivity copper alloy fuse clips |
| Standard | All fuse blocks meet the requirements of UL 4248 UL Listed guide IZLT, File E52283 CSA Certified class 6225, File 32169 |
| UPC | 782001674700 |
| GTIN | 00782001674700 |
| Item Type | UL/CSA Fuse Bases |
| Size | 3.05 x 1.62 x 1.45 |
| Voltage Rating | 600 |
