Telemecanique

XCKP2118N12X1 OsiSense XC Standard Format Fixed Limit Switch, 240 V AC, 10 A, Spring Return Plunger Actuator, 1NO-1NC Contact, 2 Poles

MFR:
Telemecanique Sensors
MFR #:
XCKP2118N12X1
UPC:
785901976493
Item #:
891943

Availability

Location Available Qty
Available Available to Order
$131.53 each

limit switch XCKP - metal end plunger - 1NC+1NO - snap

Manuals and Documentation
Catalog Number XCKP2118N12X1
Manufacturer Telemecanique Sensors
Brand Telemecanique
Warranty Description Contractual Warranty:18 months
Country of Origin France
Made in USA No
Action Vertical approach, 1 direction;Snap action;On end
Actuator Spring return plunger metal
Amperage Rating 3
Application COMPACT VARIABLE
Connection Male connector M12, 4 pins
Contact Configuration 1 NC + 1 NO
Mounting By The Body
Operating Cycles 5000000 CYCLES, DC-13, 120 V, 4 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13, 24 V, 10 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13, 48 V, 7 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C
Special Features FIXED,PLASTIC
Standard 25 GN 10-500 HZ)IEC 60068-2-6,50 GN 11 MS IEC 60068-2-27,EN 60947-5-1-UL 508-CSA C22.2 NO 14-IEC 60204-1-EN 60204-1-IEC 60947-5-1,IK04 EN 50102,IP66 IEC 60529-IP67 IEC 60529,UL-CCC-CSA,CLASS II IEC 61140-CLASS II NF C 20-030
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=55955285&lang=en-us
UPC 785901976493
GTIN 00785901976493
Item Type Limit switch
Size 30 MM,31 MM,65-65 MM
Operating Temperature -25-70 A Degrees C
Voltage Rating 3 A 240 V, AC-15 EN/IEC 60947-5-1 APPENDIX A-0.27 A 250 V, DC-13 EN/IEC 60947-5-1 APPENDIX A
