Telemecanique

XMLK200P2D23 OsiSense XM Fixed Differential Electronic Pressure Sensor, 0 to 200 psi, <5 ms Response, Analog Output, 24 V DC

MFR:
YAGEO Corporation
MFR #:
XMLK200P2D23
UPC:
785901697930
Item #:
885641

Availability

Location Available Qty
Available Available to Order
$180.20 each

Type XMLK pressure transmitters are characterized by their ceramic pressure measuring cell. Deformation, caused by pressure, changes the resistance of the resistors of a Wheatst1-bridge silk screened on the ceramic. The change in resistance is then processed by the integrated electronics to provide an analog output signal.

Manuals and Documentation

Features

  • High accuracy for your very demanding process
  • User friendly electronic sensors which can be mounted and configured very simply
  • Without display
Manufacturer Part Number XMLK200P2D23
Brand Telemecanique
Manufacturer YAGEO Corporation
UPC 785901697930
EAN 3389119049047
Country Of Origin ID
Amperage Rating <20 mA
Dimensions 1.42 in Dia x 2.58 in L
Series XMLK
Temperature Rating 0 to 80 deg C
Type Fixed Differential
Voltage Rating 24 V DC
Alternative Part Number 11785154
Manufacturer Item Status Active
Country USA/Canada
Warranty 18 months
Standards Approvals RoHS Compliant | IEC Certified | CE Certified | ECCN: EAR99 | PROP65: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Application For industrial applications such as material handling by suction pad, vacuum former, water pumping, treatment, irrigation, air compressor, machine tools, molding machine, stamping machine, press, mobile crane, HVAC, railway, more generally all pneumatic or hydraulic industrial systems, provides a high degree of accuracy for controlling water pressure in your pumping and industrial applications
Connection Size 4-Pin M12 Male/1/4 in to 18
Output Analog
Response Time <5 ms
Sensing Range 0 to 200 psi
