U6012-XL-200-K1-ALT 4 Term, Ringless, Small Closing Plate, Lever Bypass, 1-200 Amp, Main Breaker, 8 Branch Circuit, Single Connector, 6-350 kcmil, Alliant Energy
- MFR:
- Milbank
- MFR #:
- U6012-XL-200-K1-ALT
- UPC:
- 784572880801
- Item #:
- 878417
U6012-XL-200-K1-ALT 4 Term, Ringless, Small Closing Plate, Lever Bypass, 1-200 Amp, Main Breaker, 8 Branch Circuit, Single Connector, 6-350 kcmil, Alliant Energy
- MFR #:
- U6012-XL-200-K1-ALT
- UPC:
- 784572880801
- Item #:
- 878417
Availability
| Location | Available Qty |
|---|---|
| Available | 14 ea |
$2,030.61
each
Manuals and Documentation
| Catalog Number | U6012-XL-200-K1-ALT |
| Manufacturer | Milbank |
| Brand | Milbank |
| Country of Origin | United States |
| Made in USA | Yes |
| Amperage Rating | 200 |
| Application | Meter Socket With Main And Load Center |
| Bypass Type | Lever |
| Cable Entry | Overhead or Underground |
| Enclosure | G90 Galvanized Steel with Powder Coat Finish |
| Frequency Rating | 60 Hertz |
| Insulation | Glass Polyester |
| Mounting | Surface Mount |
| Number of Jaws | 4 Terminal |
| Phase | 1 |
| Standard | UL Listed;Type 3R |
| UPC | 784572880801 |
| GTIN | 00784572880801 |
| Item Type | Ringless Meter Socket |
| Size | 4.5L x 14.13W x 39.25H |
| Voltage Rating | Up to 240 Volts Alternating Current |
