Square D

PLL34000S12 PowerPact Automatic Molded Case Circuit Breaker, 480 V AC, 1200 A, 125 kA at 240 V AC, 100 kA at 480 V AC Interrupt, 3 Poles, Magnetic Trip

MFR:
Schneider Electric
MFR #:
PLL34000S12
UPC:
785901696612
Item #:
858744

Availability

Location Available Qty
Available Available to Order

PowerPacT P-Frame automatic switches are a disconnect device and can be used to open and close a circuit under normal operating conditions. The automatic switches are similar in construction, use the same accessories, and offer the same connection possibilities as the P-Frame circuit breaker version. The switches have a factory set, nonadjustable trip point calibrated to protect the molded case switch. The automatic switch can make and break its rated current. For an overload or a short circuit, it must be protected by an upstream device. PowerPacT P-Frame switches are available in unit mount, I-Line, plug-in, or drawout versions. This switch has lugs on both the line and load sides. This PowerPacT P, 1200A, 3 pole, automatic switch has a short circuit withstand current rating of 100kA at 480VAC. PowerPacT P automatic switches comply to UL and CSA standards.

Manuals and Documentation
Catalog Number PLL34000S12
Manufacturer Schneider Electric
Brand Square D
Warranty Description Contractual Warranty:18 months
Country of Origin United States
Made in USA Yes
Connection Lugs, line;lugs, load;4 x AWG 3/0...500 kcmil ( aluminium/copper )
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=61670129&lang=en-us
UPC 785901696612
GTIN 00785901696612
Width 16.54
Width UOM Inch
Height 16.24
Height UOM Inch
Depth 14.49 IN
