260R202 Rectangular Window Current Transformer, 2000:5 Current Ratio, 2000 A Primary, 5 A Secondary, 600 V, 50 to 400 Hz
- MFR:
- Schneider Electric
- MFR #:
- 260R202
- Item #:
- 8562
260R202 Rectangular Window Current Transformer, 2000:5 Current Ratio, 2000 A Primary, 5 A Secondary, 600 V, 50 to 400 Hz
- MFR #:
- 260R202
- Item #:
- 8562
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
Square D™ Current Transformer, Rectangular Window, Series: 260R, 2000:5 Current Ratio, 2000 A Primary Current, 5 A Secondary Current, 600 V, 50 to 400 Hz Frequency, 1 ph, 0.3 % Accuracy, Screw Clamp Connection, Panel Mounting, 10 kV BIL Full Wave Insulation, NEMA 1 Enclosure, 30 to 55 deg C, Thermoplastic Housing Material, 4.88 in W x 2.12 in D x 7.25 in H Dimensions
Manuals and Documentation
Features
- High thermal ratings for short time use
- Molded thermoplastic cases
- Permanent polarity marks molded into case and large easy to read ratios
- Low energy loss, grain oriented silicon steel annealed for optimum magnetic qualities
- Rugged mounting brackets
| Manufacturer Part Number | 260R202 |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| EAN | 3606481947444 |
| Country Of Origin | US |
| Dimensions | 4.88 in W x 2.12 in D x 7.25 in H |
| Enclosure Type | NEMA 1 |
| Housing Material | Thermoplastic |
| Mounting Type | Panel |
| Series | 260R |
| Temperature Rating | 30 to 55 deg C |
| Type | Rectangular Window |
| Voltage Rating | 600 V |
| Alternative Part Number | 14893771 |
| Manufacturer Item Status | Discontinued |
| Country | USA |
| Warranty | 18 months |
| Standards Approvals | ANSI C57.13 | CSA File No. C13 | UL Listed | cUL Recognized | REACH Compliant | RoHS Compliant | PROP65: This product can expose you to chemicals including Formaldehyde, which is known to the State of California to cause cancer and methanol which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. |
| Application | Indoor, Switchgear Assemblies, Motor Controllers, Over Power Transformer Bushings, Over Circuit Breaker Bushings, Monitoring, Metering, Relaying and Current Sensing Applications |
| Accuracy | 0.3 % |
| Connection Type | Screw Clamp |
| Current Ratio | 2000:5 |
| Frequency Rating | 50 to 400 Hz |
| Insulation | 10 kV BIL Full Wave |
| Phase | 1 |
| Primary Current | 2000 A |
| Secondary Current | 5 A |
