XSDC407139 OsiSense XSD Series Fixed Form Proximity Sensor, Inductive, Discrete Output, 1NO Contact, 12 to 48 V DC
- MFR:
- Telemecanique Sensors
- MFR #:
- XSDC407139
- UPC:
- 785901619734
- Item #:
- 839158
XSDC407139 OsiSense XSD Series Fixed Form Proximity Sensor, Inductive, Discrete Output, 1NO Contact, 12 to 48 V DC
- MFR #:
- XSDC407139
- UPC:
- 785901619734
- Item #:
- 839158
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
This product is part of the XS range, an offer of inductive proximity sensors. This general purpose inductive proximity sensor has a form 80mm x 80mm x 40mm design and fixed body. It is non-flush mountable and has a frontal detection face. It supports 40mm nominal sensing distance and 1 NO discrete output. The inductive proximity sensor with a rated supply voltage of 12V to 48V DC. It is furnished with screw clamp terminals for electrical connection. It is an IP67 rated product. The enclosure is made of plastic. Its dimensions are 80mm (width) x 40mm (depth) x 100mm (height). It is suitable for railway, mobile equipment, material handling/conveying/logistics, material working/machine tools, packaging, robotics, food and beverage industries. This product is certified by CE and CCC. Inductive sensors come in flush and non-flush versions, M8, M12, M18, M30 short and long bodies cylindrical forms, standard cubic, rectangular and flat forms. The inductive proximity sensors for non contact sensing of metal objects up to 60mm. It is designed for use in industrial applications relating to presence detection.
Manuals and Documentation
| Catalog Number | XSDC407139 |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Morocco |
| Made in USA | No |
| Application | General purpose;- |
| Connection | Screw-clamp terminals |
| Connector | SCREW-CLAMP TERMINALS |
| Enclosure | Plastic |
| Material | Plastic |
| Mounting | Flush |
| Output | 1 NO;Discrete;DC |
| Sensing Range | 40 MM,> 0.59...1.57 IN (> 15...40 MM) |
| Sensor | 100 MM,INDUCTIVE PROXIMITY SENSOR |
| Special Features | Frontal |
| Standard | IP67;CE |
| Supply Voltage | 12...48 V DC |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=871300&lang=en-us |
| UPC | 785901619734 |
| GTIN | 03389110619737 |
| Item Type | Inductive proximity sensor |
| Operating Temperature | -25-70 A Degrees C |
| Voltage Rating | 12...48 V DC |
