Discontinued
9012GEW22 1-Stage High Pressure Electromechanical Pressure Switch, 20 to 675 psi Pressure, 27 psi Differential, 2NO-2NC DPDT-DB Contact, Screw Clamp Connection
- MFR:
- Schneider Electric
- MFR #:
- 9012GEW22
- UPC:
- 785901348696
- Item #:
- 838620
Discontinued
9012GEW22 1-Stage High Pressure Electromechanical Pressure Switch, 20 to 675 psi Pressure, 27 psi Differential, 2NO-2NC DPDT-DB Contact, Screw Clamp Connection
- MFR #:
- 9012GEW22
- UPC:
- 785901348696
- Item #:
- 838620
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
pressure switch 9012G - fixed scale - 1 threshold - 20 to 675 psig
Manuals and Documentation
| Catalog Number | 9012GEW22 |
| Manufacturer | Schneider Electric |
| Brand | Square D |
| Warranty Description | Contractual Warranty: 18 months |
| Country of Origin | Mexico |
| Made in USA | No |
| Application | Detection of 1 single threshold;Control circuit |
| Contact Configuration | 2(NC-NO), DPDT-DB, Form ZZ, snap action, silver nickel contacts |
| Enclosure | Die cast aluminium alloy 380 |
| Operating Cycles | 120 CYC/MN |
| Process Connection | 0.25 INCH 18 NPTF UL 508 |
| Special Features | SCREW-CLAMP TERMINALS, AWG 22...AWG 12 |
| Standard | UL 508-CE-CSA C22.2 NO 14,UL LISTED FILE E12158 CCN NKPZ AND CCN NTHT-CE-CSA LR25490 CLASS 3211 03 |
| UPC | 785901348696 |
| GTIN | 00785901348696 |
| Item Type | Electromechanical pressure switch;Fixed |
| Environmental Conditions | WATER TIGHT, DUST TIGHT, OIL TIGHT AND CORROSION RESISTANT (INDOOR/OUTDOOR) |
| Operating Temperature | -10-185 A Degrees F |
| System Pressure | 2000 |
