Discontinued
Square D

9007C66G Heavy Duty Plug-In Limit Switch, 600 V, 10 A, Side Plunger Actuator, 2(NC-NO), Form Z 2SPDT-DB Contact, 2 Poles

MFR:
Schneider Electric
MFR #:
9007C66G
UPC:
785901538387
Item #:
838459

Availability

Location Available Qty
Available Available to Order

LIMIT SWITCH 600V 10AMP C +OPTIONS

Manuals and Documentation
Catalog Number 9007C66G
Manufacturer Schneider Electric
Brand Square D
Country of Origin Mexico
Made in USA No
Action LATERAL APPROACH, 1 DIRECTION,ON END,SNAP ACTION
Actuator STAINLESS STEEL SPRING RETURN SIDE PLUNGER -)
Amperage Rating 10
Application STANDARD BOX
Connection SCREW-CLAMP TERMINALS AWG 22...AWG 12), 1-2
Contact Configuration 2(NC-NO)
Contact Rating NEMA A600/R300
Enclosure NEMA 1 NEMA TYPE 250-NEMA 2 NEMA TYPE 250-NEMA 4 NEMA TYPE 250-NEMA 6 NEMA TYPE 250-NEMA 6P NEMA TYPE 250-NEMA 12 NEMA TYPE 250-NEMA 13 NEMA TYPE 250
Mounting By The Body
Operating Cycles 1000000 CYCLES
Special Features WITHOUT
Standard 25 GN 10-150 HZ)IEC 60068-2-6,60 GN 9 MS IEC 60068-2-27,IP67 IEC 60529,CLASS 0 IEC 61140
UPC 785901538387
GTIN 00785901538387
Item Type LIMIT SWITCH,PLUNGER HEAD
Size 1.55 IN,2.16 IN,4.02-4.02 IN
Environmental Conditions STANDARD ENVIRONMENT
Operating Temperature -20-185 A Degrees F STANDARD ENVIRONMENT
Voltage Rating 1.2 A 600 V AC, A600 NEMA-1.5 A 480 V AC, A600 NEMA-3 A 240 V AC, A600 NEMA-6 A 120 V AC, A600 NEMA-0.11 A 250 V DC, R300 NEMA-0.55 A 125 V DC, R300 NEMA
