SCHNEIDER ELECTRIC

LC1D65A3BD TeSys D Contactor With Safety Cover, 24 V DC V Coil, 1000 A, 3NO Contact, 3 Poles

MFR:
Schneider Electric
MFR #:
LC1D65A3BD
Item #:
830933

Availability

Location Available Qty
Available 4 ea
$653.57 each

TeSys Deca contactor, 3 poles (3NO), for motor control applications up to 65A/690V AC-3/3e (30kW@400V). They can be used to create motor starters for almost any type of application. It provides a 24V DC coil with transient suppressor module, 1NO+1NC built-in auxiliary contacts (NC mirror certified), power connection by EverLink BTR screw connectors, control connection by spring terminals. For operating rates until 3600 cycles/hour and environments until 60C, it procures high reliability and durability. Compact (55mm width), DIN-rail mounting or screw fixing. Contactor is rated for 20HP at 200 to 208VAC, 20HP at 240VAC, 40HP at 480VAC and 50HP at 600VAC three phase. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine). Contactor is supplied with a 24 VDC coil with transient suppressor module. Contactor has one normally open and one normally closed auxiliary contact built-in as standard. The NC contact is mirror certified. Spring terminals are used for load and auxiliary connections. An extensive line of accessories makes it easy to meet the requirements of most applications. The contactor is 4.80 inches tall, 2.17 inches wide and 4.72 inches deep. It weighs 2.06 lbs. Contactor is certified to UL, CSA, IEC, CCC, EAC and Marine standards.

Manuals and Documentation
Catalog Number LC1D65A3BD
Manufacturer Schneider Electric
Brand SCHNEIDER ELECTRIC
Warranty Description Contractual Warranty:18 months
Country of Origin France
Made in USA No
Operating Cycles 50 ±15 % ms closing;16...24 ms opening
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=1472753&lang=en-us
GTIN 03389119409193
