FXCS-5B4 Double Pushbutton With Box and Cover, 3/4 in, Green/Red
- MFR:
- Killark, a Hubbell affiliate
- MFR #:
- FXCS-5B4
- UPC:
- 783936202280
- Item #:
- 816503
FXCS-5B4 Double Pushbutton With Box and Cover, 3/4 in, Green/Red
- MFR #:
- FXCS-5B4
- UPC:
- 783936202280
- Item #:
- 816503
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$1,727.19
each
Manuals and Documentation
| Catalog Number | FXCS-5B4 |
| Manufacturer | Killark, a Hubbell affiliate |
| Brand | Killark |
| Country of Origin | China |
| Made in USA | No |
| Action | Momentary |
| Actuator | Double Pushbutton |
| Amperage Rating | 10 |
| Application | SEAL-X Series is used to prevent the igniting of external hazardous atmospheres by the enclosed arcing devices in such areas as: hazardous locations due to the presence of flammable gases or vapors, combustible dusts or easily ignitable fibers or flyings |
| Color | Green;Red |
| Contact Configuration | 1-NO/1-NC |
| Contact Rating | 60A INRUSH @ 120 VAC; 30A INRUSH @ 240 VAC; 15A INRUSH @ 480 VAC; 12A INRUSH @ 600 VAC; 6A BREAKING @ 120 VAC; 3A BREAKING @ 240 VAC; 1.5A BREAKING @ 480 VAC; 1.2A BREAKING @ 600 VAC; 10A CARRYING @ 120 VAC; 10A CARRYING @ 240 VAC; 10A CARRYING @ 480 VAC; |
| Enclosure | Aluminum factory sealed feed-thru splice box |
| Number of Poles | 2 |
| Special Features | Killark SEAL-X Series Factory Sealed Control Stations provide control solutions in hazardous location areas to supply; START/STOP Motor Functions, LED Pilot Light Indications and more. Utilized in Class 1 Division 1 & 2, Class 1 Zone 1 & 2 areas where Type 3, 7 & 9 protection ratings are required for indoor and outdoor use. UL Listed and CSA Certified. |
| Standard | UL, CSA |
| UPC | 783936202280 |
| GTIN | 00783936202280 |
| Item Type | Factory Sealed |
| Size | 6.63 in x 6 in x 4.38 in |
| Environmental Conditions | Hazardous locations |
| Voltage Rating | 600 VAC maximum |
