FWH-020A6F FWH High Speed Cartridge Fuse, 20 A, 500 VAC/VDC, 20 to 50 kAIC interrupt, class: 3AG, Cartridge Fuses body
- MFR:
- Eaton Bussmann
- MFR #:
- FWH-020A6F
- UPC:
- 051712796729
- Item #:
- 81088
FWH-020A6F FWH High Speed Cartridge Fuse, 20 A, 500 VAC/VDC, 20 to 50 kAIC interrupt, class: 3AG, Cartridge Fuses body
- MFR #:
- FWH-020A6F
- UPC:
- 051712796729
- Item #:
- 81088
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristors (GTOs) and IGBTs and in light and heavy harsh DC traction applications as high as 4000Vdc and 10,000A. Also used for the protection of DC link/power converters. Optimized dimensions and materials allow for excellent thermal dissipation for high current cycling enviroments, or heavy duty applications.
| Catalog Number | FWH-020A6F |
| Manufacturer | Eaton Bussmann |
| Brand | Eaton Bussmann Series |
| Country of Origin | Multiple |
| Made in USA | No |
| Application | Ind Facilities & Factories - Facility: Safety and Security Systems |
| Connection | Ferrule end x ferrule end |
| Interrupt Rating | 50 kAIC at 0.25-20A|20 kAIC at 25-30A |
| Response Time | <30 min at 150%, <30 min at 200%, <=10 sec at 300% |
| Standard | CSA Certified ,UL Recognized,CE Marked |
| UPC | 051712796729 |
| GTIN | 00051712796729 |
| Item Type | High speed fuse |
| Weight UOM | Pounds |
| Voltage Rating | 500 Vac/dc (35-800 A only) |
