HBL45335 Heavy Duty Standard Sized Isolated Grounding Cord Mount Female Connector, 600 V AC/250 V DC, 30 A, 4 Poles, 5 Wires, Black

MFR:
Hubbell Wiring Device-Kellems
MFR #:
HBL45335
UPC:
783585236582
Item #:
806657

Availability

Location Available Qty
Available Available to Order
$407.71 each

Variload Twist-Lock Devices - In many large plants and laboratories the number of circuits of different ratings and frequency is greater than the number of blade configurations available in conventional wiring devices. Prior to NEMA configuration standardization the solution was Variload Twist-Lock devices with four non-interchangeable center pin and slot configurations that can be assigned within the same premises to circuits of same voltage, frequency and supply (AC or DC), in accordance with NEC 406.4(F) and 406.8 and with CE Code, Part I, Rule 26-700(3).

Manuals and Documentation
Catalog Number HBL45335
Manufacturer Hubbell Wiring Device-Kellems
Brand Hubbell Wiring Device - Kellems
Country of Origin United States
Made in USA Yes
Amperage Rating 30
Application Heavy Duty Industrial
Color Black
Conductor Range #12AWG to #8AWG
Connection Pressure Screw Terminal
Insulation Insulated Body
Material Composite
Mounting Cord
Number of Conductors 5-Wire Grounding
Number of Poles 4
Special Features Unique Center Pin
Standard Certified to CSA C22.2 No.42;Listed to UL 498
UPC 783585236582
GTIN 00783585236582
Item Type Connector Body
Size 2.13 in x 2.13 in x 3.79 in
Environmental Conditions Indoor Dry Unless Protected By Additional Means
Temperature Rating Maximum Continuous: 75 Degrees C; Minimum Continuous: -40 Degrees C w/o impact, -25 Degrees with impact.
Voltage Rating 250 VDC/600
