Discontinued
HL100WNCS2M34 L100 Severe Duty Mill Limit Switch, 600 V, 10 A, 1NC+1NO, 2NC, Form YY DPST-NC-DB Contact, 2 Poles
- MFR:
- Schneider Electric
- MFR #:
- HL100WNCS2M34
- UPC:
- 785901635772
- Item #:
- 802458
Discontinued
HL100WNCS2M34 L100 Severe Duty Mill Limit Switch, 600 V, 10 A, 1NC+1NO, 2NC, Form YY DPST-NC-DB Contact, 2 Poles
- MFR #:
- HL100WNCS2M34
- UPC:
- 785901635772
- Item #:
- 802458
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
L100 mill limit switch - 2 contacts - spring return - CW+CCW - 1/2" NPT
Manuals and Documentation
| Catalog Number | HL100WNCS2M34 |
| Manufacturer | Schneider Electric |
| Brand | Square D |
| Country of Origin | Mexico |
| Made in USA | No |
| Action | CW AND CCW-FROM LEFT OR RIGHT,LATERAL APPROACH,SNAP ACTION |
| Actuator | SPRING RETURN WITHOUT OPERATING LEVER |
| Amperage Rating | 20 |
| Application | MILL SWITCH |
| Connection | SCREW-CLAMP TERMINALS AWG 22...AWG 12 |
| Contact Configuration | 2 NC |
| Contact Rating | NEMA A600/P600 |
| Enclosure | NEMA 1 NEMA TYPE 250-NEMA 2 NEMA TYPE 250-NEMA 4 NEMA TYPE 250-NEMA 12 NEMA TYPE 250-NEMA 13 NEMA TYPE 250 |
| Mounting | By The Body |
| Special Features | FIXED,NEUTRAL POSITION |
| Standard | 10 GN 10-55 HZ)IEC 60068-2-6,30 GN 9 MS IEC 60068-2-27,IP67 IEC 60529,CLASS 0 IEC 61140 |
| UPC | 785901635772 |
| GTIN | 00785901635772 |
| Item Type | LIMIT SWITCH,ROTARY HEAD |
| Size | 2.25 IN,3.41 IN,4.95-4.95 IN |
| Operating Temperature | 0-350 A Degrees F |
| Voltage Rating | 600V |
