Discontinued
Square D by Schneider Electric

JGL36200LC Circuit Breaker, 600 V AC, 200 A, 20 to 65 kA interrupt, 3 poles, Thermal Magnetic trip

MFR:
Schneider Electric
MFR #:
JGL36200LC
UPC:
785901602385
Item #:
782604

Availability

Location Available Qty
Available Available to Order

The PowerPact J-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. J-frame circuit breakers are available with either thermal-magnetic or Micrologic electronic trip units. The amperage ratings of the thermal trip elements are calibrated at 104F (40C) free air ambient temperature. Per the National Electric Code (NEC) and the Canadian Electrical Code, standard circuit breakers may only be applied continuously at up to 80% of their rating. This PowerPact J, circuit breaker and is 3-pole and has a breaking capacity of 65kA@240VAC and has a rated current of 200A. This ia a unit mount breaker and complies to UL listed, IEC, CCC, CE & CSA standards. With a magnetic hold current of 1000A and a magnetic tripping current of 2000-2000A Dimensions for this product are 7.52 in (H),4.12 in (W), 5 in (D) with an ambient temperature rating of 40 C. This product comes with an 18 month warranty.

Manuals and Documentation
Catalog Number JGL36200LC
Manufacturer Schneider Electric
Brand Square D by Schneider Electric
Warranty Description Contractual Warranty: 18 months
Country of Origin United States
Made in USA Yes
Number of Poles 3
RoHS URL https://download.schneider-electric.com/files?p_Doc_Ref=JGL36200LC_ROHS_DECLARATION&p_FileName=JGL36200LC_ROHS_DECLARATION_US_en-US.pdf
UPC 785901602385
GTIN 00785901602385
Width 4.12
Width UOM Inch
Height 7.52
Height UOM Inch
