Discontinued
Telemecanique

XS7C4A1MPP20 OsiSense XS Fixed General Purpose Proximity Sensor, Inductive, AC/DC Output, 1NO-1NC Contact, 24 to 240 V AC

MFR:
Telemecanique Sensors
MFR #:
XS7C4A1MPP20
Item #:
743349

Availability

Location Available Qty
Available Available to Order
$286.02 each

The XS range is an offer of inductive proximity sensors for the detection, without physical contact, of metal objects. The advantages of inductive detection are numerous, no physical contact with the object to be detected. Thus avoiding wear and enabling detection of fragile or freshly painted objects. High operating rates. Fast response. Excellent resistance to industrial environments (robust products, fully encapsulated in resin). This product is a 40mm x 40mm x 117mm format sensor, flush mountable in metal. It features a plastic case with a plug-in 5 position turret head and a ISO M20 cable entry. It has a sensing distance of 15mm. Two-wire, AC and DC supply, 24V to 240V, NO or NC function programmable.

Manuals and Documentation

Features

  • Discontinued
Catalog Number XS7C4A1MPP20
Manufacturer Telemecanique Sensors
Brand Telemecanique
Warranty Description Contractual Warranty:18 months
Country of Origin Mexico
Made in USA No
Application -
Connector Screw-clamp terminals, 4 x 1.5 mm²
Enclosure PBT
Indicator Supply on 1 LED green);output state 1 LED yellow)
Material Plastic
Mounting Flush
Sensing Range > 0.31...0.59 IN (> 8...15 MM)
Special Features IP65 CONFORMING TO IEC 60529-IP67 CONFORMING TO IEC 60529-IP69K CONFORMING TO DIN 40050,SCREW-CLAMP TERMINALS, CLAMPING CAPACITY: 4 X 1.5 MM²
Standard IP67 conforming to IEC 60529;IP65 conforming to IEC 60529;IP69K conforming to DIN 40050;CE
Supply Voltage 24...240 V AC 50/60 Hz;24...240 V DC
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=181658553&lang=en-us
GTIN 03389119058155
Item Type Inductive proximity sensor;Form 40 x 40 x 117
Operating Temperature -25-70 A Degrees C
