110FXE2-SC-15 N-Tron 10-Port Unmanaged Ethernet Switch, (8) 10/100BaseTX RJ-45, (2) 100BaseFX Single-Mode Fiber Ports With SC Connectors Port, 3.2 Gbps Switching
- MFR:
- Red Lion Controls
- MFR #:
- 110FXE2-SC-15
- Item #:
- 716207
110FXE2-SC-15 N-Tron 10-Port Unmanaged Ethernet Switch, (8) 10/100BaseTX RJ-45, (2) 100BaseFX Single-Mode Fiber Ports With SC Connectors Port, 3.2 Gbps Switching
- MFR #:
- 110FXE2-SC-15
- Item #:
- 716207
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
The N-TRON® 110FX2 unmanaged industrial network switch is designed to meet the most demanding communications requirements while providing high throughput and minimum downtime. The 10-port Ethernet Switch is the perfect low cost solution for mission critical data acquisition, control and Ethernet I/O applications.
Manuals and Documentation
Features
- Unmanaged plug and play operation
- Auto sensing duplex, speed and MDIX (RJ-45 ports)
- Full wire speed communication
- Store and forward technology
- Compact, space saving package
- ESD and surge protection on all built-in ports
- Surge protection diodes on power inputs
- LED link/activity status indication
- Hardened metal DIN rail enclosure
| Manufacturer Part Number | 110FXE2-SC-15 |
| Brand | redlion® |
| Manufacturer | Red Lion Controls |
| Height | 4-1/4 in |
| Mounting Type | DIN Rail |
| Series | N-Tron® |
| Temperature Rating | -40 to 80 deg C |
| Type | 10-Port Unmanaged |
| Width | 2.4 in |
| Manufacturer Item Status | Active |
| Country | USA |
| Standards Approvals | ABB Approved | ANSI C63.4 | CE IEC/EN 61000-4-2/3/4/5/6/8/11/61000-6-2/4 | cPT Listed | cULus File No. 65SN | FCC Title 47 Part 15 Subpart B Class A | GOST-R Certified | ICES-003 | IEEE 802.3 | RoHS Compliant | UL/cUL Class I Division 2 Groups A/B/C/D/T4 |
| Application | For mission critical data acquisition, control, Ethernet I/O, shipboard and industrial applications |
