DMC1053 Warm Tiles Decoupling Membrane Electric Floor Warming Cable, 2 Conductors, 120 V AC, 5.5 A, 21.7 Ohm
- MFR:
- Emerson Electric
- MFR #:
- DMC1053
- UPC:
- 013627188167
- Item #:
- 695467
DMC1053 Warm Tiles Decoupling Membrane Electric Floor Warming Cable, 2 Conductors, 120 V AC, 5.5 A, 21.7 Ohm
- MFR #:
- DMC1053
- UPC:
- 013627188167
- Item #:
- 695467
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$405.58
each
Warm Tiles™ electric floor warming cable for uncoupling membrane (DMC) is the easy to install, reliable solution for your floor warming project. The cable is specially designed to be used with all available uncoupling membranes and Warm Tiles™ DMC cable strapping strips, so installation could not be simpler. DMC cables are designed to gently warm flooring materials such as marble, ceramic, glass and porcelain tile, slate, granite, poured or dimensional stone, laminate and certain engineered hardwood products.
Manuals and Documentation
Features
- Heating area range from 7 to 250 sq-ft (0.7 to 23 sq-m)
- Cable can be laid directly from the spool into the membrane in whatever configuration you need
- Once the cable is installed, tile installation is easy - self-leveling or scratch coat may not be required
- Approved for a variety of applications and floor finishes for the ultimate in versatility and compatibility
- Cables can also be installed in steps, including risers, leading to a bath/shower area in most jurisdictions
- Check with your local electrical inspector before installing in steps
- Cables can be installed in tiled showers or other wet areas, although it is recommended that you check with your local electrical inspector first to verify that this application is allowed in your jurisdiction
| Manufacturer Part Number | DMC1053 |
| Brand | EasyHeat® |
| Manufacturer | Emerson Electric |
| UPC | 013627188167 |
| Country Of Origin | MX |
| Amperage Rating | 5.5 A |
| Color | Beige |
| Finish | Smooth |
| Insulation Material | PVC |
| Jacket Material | PVC |
| Number Of Conductors | 2 |
| Outside Diameter | 0.187 in |
| Strands | 1 |
| Temperature Rating | 104 deg F |
| Type | Decoupling Membrane |
| Voltage Rating | 120 V AC |
| Wattage | 665 W |
| Alternative Part Number | 13220461 |
| Manufacturer Item Status | Active |
| Country | USA |
| Standards Approvals | cCSAus, CSA US Certified |
| Application | For uncoupling membrane systems, marble, ceramic, glass, porcelain tile, slate, granite, poured or dimensional stone, laminate, certain engineered hardwood products floor, residential, commercial and industrial applications |
| Conductor Material | Copper |
| Core | Copper |
| Resistance | 21.7 Ohm |
