Tri-Pac NB3800PF Molded Case Circuit Breaker Frame, 600 V AC/250 V DC, 800 A, 3 Poles, Pressure Line/Load Terminal
- MFR:
- Eaton
- MFR #:
- NB3800PF
- UPC:
- 786679910443
- Item #:
- 680738
Tri-Pac NB3800PF Molded Case Circuit Breaker Frame, 600 V AC/250 V DC, 800 A, 3 Poles, Pressure Line/Load Terminal
- MFR #:
- NB3800PF
- UPC:
- 786679910443
- Item #:
- 680738
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$26,140.09
each
Classic mining service circuit breakers continue to be manufactured and are primarily applied to achieve an exact physical and electronic replacement of previously Cutler-Hammer installed Westinghouse equipment. To upgrade to the current offering of E2 mining circuit breakers, consult the cross reference information.
| Catalog Number | NB3800PF |
| Manufacturer | Eaton |
| Brand | Eaton |
| Country of Origin | United States |
| Made in USA | Yes |
| Application | Elec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs |
| Current Rating | 800 A |
| Interrupt Rating | 200 kAIC at 600 Vac|100 kAIC at 250 Vdc |
| Number of Poles | 3 |
| Standard | UL 489 |
| UPC | 786679910443 |
| GTIN | 00786679910443 |
| Item Type | Molded case circuit breaker |
| Dimensions | 25.0000 IN X 10.0000 IN X 8.1000 IN |
| Trip Type | Fixed thermal, fixed magnetic |
| Voltage Rating | 600 Vac, 250 Vdc |
