XMLG001D21SAL OsiSense XM Electronic Pressure Sensor, 0 to 1 bar, <2 ms Response, Analog Output, 12/24 V DC
- MFR:
- Telemecanique Sensors
- MFR #:
- XMLG001D21SAL
- Item #:
- 68045
XMLG001D21SAL OsiSense XM Electronic Pressure Sensor, 0 to 1 bar, <2 ms Response, Analog Output, 12/24 V DC
- MFR #:
- XMLG001D21SAL
- Item #:
- 68045
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$369.08
each
PRESSURE SWITCH WITH SETTING AT 0 - 7.25 P
Manuals and Documentation
| Catalog Number | XMLG001D21SAL |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Mexico |
| Made in USA | No |
| Application | Control circuit |
| Enclosure | NEMA 4 |
| Process Connection | G 1/4A (MALE) DIN 3852-E |
| Special Features | 3 PINS 1 MALE CONNECTOR M12,IP66 CONFORMING TO EN/IEC 60529-IP67 CONFORMING TO EN/IEC 60529 |
| Standard | 1 KV 42 OHM EN/IEC 61000-4-5-500 KV 12 OHM EN/IEC 61000-4-5,15 KV IN AIR EN/IEC 61000-4-2-8 KV ON CONTACT EN/IEC 61000-4-2,200 V/M 80-1000 HZ EN/IEC 61000-4-3,30 A/M 50 HZ EN/IEC 61000-4-8,30 V 0.15-80 HZ)EN/IEC 61000-4-6,4 KV EN/IEC 61000-4-4,CE-EN/IEC 61326-2-3,IP66 EN/IEC 60529-IP67 EN/IEC 60529,UL 508-CSA C22.2 NO 14-EAC |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=7047525&lang=en-us |
| GTIN | 03389119044714 |
| Item Type | Pressure transmitter;Electronic pressure sensors |
| Operating Temperature | -15-85 A Degrees C |
| System Pressure | 14.50 |
| Temperature Rating | -15…125 DEGRESS C |
