Discontinued
9012GDW5Z16 Single Stage Low Pressure Electromechanical Pressure Switch, 3 to 150 psi Pressure, 6 psi Differential, 1CO SPDT-DB Contact, Screw Clamp Connection
- MFR:
- Schneider Electric
- MFR #:
- 9012GDW5Z16
- UPC:
- 785901774747
- Item #:
- 67916
Discontinued
9012GDW5Z16 Single Stage Low Pressure Electromechanical Pressure Switch, 3 to 150 psi Pressure, 6 psi Differential, 1CO SPDT-DB Contact, Screw Clamp Connection
- MFR #:
- 9012GDW5Z16
- UPC:
- 785901774747
- Item #:
- 67916
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
pressure switch 9012G - fixed scale - 1 threshold - 3.0 to 150 psig
Manuals and Documentation
| Catalog Number | 9012GDW5Z16 |
| Manufacturer | Schneider Electric |
| Brand | Square D |
| Warranty Description | Contractual Warranty: 18 months |
| Country of Origin | Mexico |
| Made in USA | No |
| Application | Detection of 1 single threshold;Control circuit |
| Contact Configuration | NC-NO, SPDT-DB, Form Z, snap action, silver nickel contacts |
| Enclosure | Die cast aluminium alloy 380 |
| Operating Cycles | 120 CYC/MN |
| Process Connection | 0.5 INCH 14 NPT-0.25 INCH 18 NPTF UL 508 |
| Special Features | SCREW-CLAMP TERMINALS, AWG 22...AWG 12 |
| Standard | CE-UL 508-CSA C22.2 NO 14,CSA LR25490 CLASS 3211 03-UL LISTED FILE E12158 CCN NKPZ AND CCN NTHT-CE |
| UPC | 785901774747 |
| GTIN | 00785901774747 |
| Item Type | Electromechanical pressure switch;Fixed |
| Environmental Conditions | WATER TIGHT, DUST TIGHT, OIL TIGHT AND CORROSION RESISTANT (INDOOR/OUTDOOR) |
| Operating Temperature | -10-185 A Degrees F |
| System Pressure | 475 |
