SSP3A225BD Zelio 3-Phase Zero Voltage Switching Solid State Relay, 25 A, 1NO 1 Form A SPST Contact, 4 to 32 V DC V Coil
- MFR:
- Schneider Electric
- MFR #:
- SSP3A225BD
- Item #:
- 626488
SSP3A225BD Zelio 3-Phase Zero Voltage Switching Solid State Relay, 25 A, 1NO 1 Form A SPST Contact, 4 to 32 V DC V Coil
- MFR #:
- SSP3A225BD
- Item #:
- 626488
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$211.29
each
This panel mount static relay accepts wiring with either bare cable, crimped cable ends, fork lugs or ring lugs Its rated current is 25 A, is controlled with a 4 to 32 V DC circuit, has a rated load voltage of 48 to 530 V AC output. It also has a test button for easy debugging, testing and commissioning It has a visual indicator showing the status of its input and a alarm output enabling a quick response to unexpected events
Manuals and Documentation
| Catalog Number | SSP3A225BD |
| Manufacturer | Schneider Electric |
| Brand | SCHNEIDER ELECTRIC |
| Country of Origin | Mexico |
| Made in USA | No |
| Connection | Screw terminals 1 x 0.2...1 x 2.5 mm², AWG 24...AWG 14) input;screw terminals 1 x 1.5...1 x 10 mm², AWG 16...AWG 8) output |
| Mounting | Panel Mount |
| Phase | 3 |
| Response Time | 8.33 ms (turn-on);8.33 ms (turn-off) |
| Special Features | LED, green input |
| Standard | IP20 |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=267287230&lang=en-us |
| GTIN | 03606480579820 |
| Item Type | Solid state relay up to 30 A |
