STPK6X10GR 10Gig TX6A Class EA Keyed Patch Cord With TX6A 10Gig Keyed Modular Plug on One End and TX6A 10Gig Non-Keyed Modular Plug on the Other End, Cat 6A, 26 AWG S/FTP Copper Shielded Stranded Conductor, 10 ft L Cord, Green
- MFR:
- Panduit
- MFR #:
- STPK6X10GR
- UPC:
- 074983118724
- Item #:
- 620087
STPK6X10GR 10Gig TX6A Class EA Keyed Patch Cord With TX6A 10Gig Keyed Modular Plug on One End and TX6A 10Gig Non-Keyed Modular Plug on the Other End, Cat 6A, 26 AWG S/FTP Copper Shielded Stranded Conductor, 10 ft L Cord, Green
- MFR #:
- STPK6X10GR
- UPC:
- 074983118724
- Item #:
- 620087
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
The TX6A 10Gig Keyed Cat 6A STP Patch Cord is a 10-Foot, Green cord constructed of 26 AWG, shielded, twisted pair, stranded, CM/LSZH cable. It's equipped with a TX6A 10Gig Keyed Modular Plug on one end and a Non-Keyed Modular Plug on the other. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
Manuals and Documentation
| Catalog Number | STPK6X10GR |
| Manufacturer | Panduit |
| Brand | Panduit |
| Country of Origin | Multiple |
| Made in USA | No |
| Application | (1) 10GBASE-T Ethernet (2) Data center I/O consolidation(3) Data center server virtualization (4) Consolidation of network interconnects(5) Back-bone aggregation(6) Parallel processing and high speed computing |
| Color | Green |
| Conductor Material | Copper |
| Jacket Material | LSZH Material |
| Plug Type | Keyed Modular Plug |
| Standard | Exceeds requirements of ANSI/TIA-568-C.2 Category 6A, IEEE 802.3an-2006, and ISO 11801 Class EA channel standards; RoHS Compliant |
| UPC | 074983118724 |
| GTIN | 00074983118724 |
| Item Type | Patch Cord |
| Length | 10.00 |
| Length UOM | Inch |
| Outside Diameter | 0.23 IN |
| Temperature Rating | 140 °F |
| Wire Size | 26 |
