Telemecanique

XCSM4102L5 XCSM Miniature Limit Switch, 300/400 V AC, 6 A, Roller Plunger Actuator, 2NO-2NC Contact, 4 Poles

MFR:
Telemecanique Sensors
MFR #:
XCSM4102L5
UPC:
785901859765
Item #:
609586

Availability

Location Available Qty
Available Available to Order
$252.13 each

This XCSM Miniature Safety Limit Switch has a roller plunger, a Zamak body and head and a 5 meter pre-cabled. It has 2 normally open and 2 normally closed snap action contacts. Its B10D reliability data is 50 000 000. It has IK06 impact resistance and IP66 / IP67 / IP68 degree of protection, makes it ideal for heavy duty use in harsh conditions. It also complies with EN/ISO 14119, EN/IEC 60204-1, EN/IEC 60947-5-1, UL 508, CSA C22.2 No 14 standards. When associated and correctly connected to an appropriate safety control unit, it conforms to Category 4, performance level PL e, SIL 3 as described in EN/ISO 13849-1, EN/IEC 61508.

Manuals and Documentation
Catalog Number XCSM4102L5
Manufacturer Telemecanique Sensors
Brand Telemecanique
Warranty Description Contractual Warranty:18 months
Country of Origin Unknown
Made in USA No
Action Lateral approach;Snap action;By 30 Degrees cam
Actuator Roller plunger
Application PLUNGER HEAD
Connection Pre-cabled
Contact Configuration 1 NC + 1 NC + 1 NO + 1 NO
Mounting By The Body
Number of Poles 4
Special Features Plastic protective cover, secured by 5-lobe socket head safety screw
Standard 25 GN 18 MS IEC 60068-2-27,5 GN 10-500 HZ)IEC 60068-2-6,CSA C22.2 NO 14-EN/IEC 60204-1-EN 1088-EN/IEC 60947-5-1-UL 508,IK06 EN 50102,IP66 IEC 60529-IP67 IEC 60529-IP68 IEC 60529,UL-CSA,CLASS I NF C 20-030-CLASS I EN/IEC 61140
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=859720&lang=en-us
UPC 785901859765
GTIN 03389110244311
Item Type Safety limit switch
Size 0.63
Operating Temperature -25-70 A Degrees C
