Safety switch, Telemecanique Safety switches XCS, metal XCSLF 4NC+2 NO, slow break, 3 entries tapped 1/2" NPT, 120 V
- MFR:
- Telemecanique Sensors
- MFR #:
- XCSLF3737533
- UPC:
- 785901981633
- Item #:
- 607065
Safety switch, Telemecanique Safety switches XCS, metal XCSLF 4NC+2 NO, slow break, 3 entries tapped 1/2" NPT, 120 V
- MFR #:
- XCSLF3737533
- UPC:
- 785901981633
- Item #:
- 607065
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$1,505.02
each
metal safety switch XCSLF-4NC+2NO- slow break - 3 entries tapped 1/2" NPT - 120V
Manuals and Documentation
| Catalog Number | XCSLF3737533 |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Indonesia |
| Made in USA | No |
| Action | Slow-break, break before make |
| Actuator | KEY OPERATED TURRET HEAD |
| Amperage Rating | 4 |
| Application | KEY OPERATED TURRET HEAD |
| Color | RED |
| Connection | Spring terminal 1 x 1.5 mm² flexible or solid cable;spring terminal 2 x 0.5 mm² flexible cables with 13 mm bared ends |
| Contact Configuration | 2 NC + 1 NO |
| Enclosure | IP66/67 |
| Number of Poles | 3 |
| Operating Cycles | 10 CYC/MN FOR MAXIMUM DURABILITY |
| Special Features | for actuator withdrawn 1 LED (orange); for actuator inserted and locked 1 LED (green);Locking on energisation and unlocking on de-energisation of solenoid |
| Standard | 10 GN 11 MS IEC 60068-2-27,5 GN 10-500 HZ)IEC 60068-2-6,CSA C22.2 NO 14-UL 508-EN/IEC 60204-1-EN 1088/ISO 14119-EN/IEC 62061-EN/IEC 60947-5-1-EN/ISO 13849-1,IP66 EN/IEC 60529 AND EN/IEC 60947-5-1-IP67,TÃŒV-CSA-UL,CLASS I EN/IEC 61140 |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=150021604&lang=en-us |
| UPC | 785901981633 |
| GTIN | 03606489413521 |
| Item Type | Safety switch |
| Size | 205-205 MM,44 MM,51 MM |
| Operating Temperature | -25-60 A Degrees C |
| Voltage Rating | 120 V - 15...10 % |
