IPLG6-3 Polaris IPLG Single Sided Entry Insulated Multi-Tap Connector, 14 to 6 AWG (Class B, C, D)/14 to 6 AWG (Class K, M, I) Copper Conductor, Plastisol
- MFR:
- NSi Industries
- MFR #:
- IPLG6-3
- UPC:
- 662381951427
- Item #:
- 60179
IPLG6-3 Polaris IPLG Single Sided Entry Insulated Multi-Tap Connector, 14 to 6 AWG (Class B, C, D)/14 to 6 AWG (Class K, M, I) Copper Conductor, Plastisol
- MFR #:
- IPLG6-3
- UPC:
- 662381951427
- Item #:
- 60179
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
The Polaris IPLG6-3 Grey Multi-Tap Single Side Entry Connector features 3 ports sized for 6 - 14 AWG wires. The body is made from aluminum alloy wrapped in a layer of plastisol insulation. Each port is specially designed for fine-stranded copper wires with a pre-installed tin plated copper ferule that collapses as the screw is tightened to form a strong connection with fine-stranded wires. Removable access plugs cover the hex screws used to tighten the connections. Installs with a hex key and torque wrench, without any tape or additional supplies. Designed for use in a wide range of splicing fine-stranded wire applications, including installation in cable trays, troughs, wire-ways, raceways, ducts and motor junction boxes.
Manuals and Documentation
| Catalog Number | IPLG6-3 |
| Manufacturer | NSi Industries |
| Brand | Polaris |
| Country of Origin | United States |
| Made in USA | Yes |
| Application | Wire Termination |
| Color | Gray |
| Finish | Plastisol Insulated |
| Material | Aluminum |
| Number of Conductors | 3 |
| Number of Poles | 1 |
| Special Features | (3) 6-14 AWG Class B,C,D - (3) 6-14 AWG Class K,M,I |
| Standard | UL 486A/B |
| UPC | 662381951427 |
| GTIN | 00662381951427 |
| Item Type | Single Sided Entry |
| Size | L=1.550 - W=1.240 - H=1.370 |
| Environmental Conditions | 90 C |
| Temperature Rating | 90 C |
| Voltage Rating | 600 V |
| Wire Size | (Class B,C,D) 6-14 AWG - (Class K,M,I) 6-14 AWG |
