QOB215EPD2100 Type QOB Class B GFI Ground Fault Miniature Circuit Breaker, 120/240 VAC, 15 A, 10 kA Interrupt, 2 Poles, Thermal Magnetic Trip

MFR:
Schneider Electric
MFR #:
QOB215EPD2100
UPC:
785901655305
Item #:
590233

Availability

Location Available Qty
Available Available to Order

QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This 2 pole QO circuit breaker is rated at 15A at 120/240VAC. This unit provides 10kA breaking capacity and bolt on mounting. This product includes a 30mA ground fault B protection and a alarm switch. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.

Manuals and Documentation
Catalog Number QOB215EPD2100
Manufacturer Schneider Electric
Brand SQUARE D
Warranty Description Contractual Warranty:18 months
Country of Origin Mexico
Made in USA No
Application NOT RATED
Connection AWG 14...AWG 8 copper;AWG 12...AWG 8 aluminium
Mounting Bolt
Number of Poles 2
Special Features PRESSURE PLATE
Standard UL LISTED-CSA
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=400691&lang=en-us
UPC 785901655305
GTIN 00785901655305
Item Type Miniature circuit-breaker
