KTK-R-8 Limitron Current Limiting Fast Acting Fuse, 8 A, 600 V, 200 kAIC Interrupt, CC Class, Cylindrical Body
- MFR:
- Eaton
- MFR #:
- KTK-R-8
- UPC:
- 051712420679
- Item #:
- 58517
KTK-R-8 Limitron Current Limiting Fast Acting Fuse, 8 A, 600 V, 200 kAIC Interrupt, CC Class, Cylindrical Body
- MFR #:
- KTK-R-8
- UPC:
- 051712420679
- Item #:
- 58517
Availability
| Location | Available Qty |
|---|---|
| Available | 24 ea |
$60.17
each
Bussmann's Class CC fuses set the standard in Class CC fuse performance in the industry. Recognized for their superior performance, Bussmann has the right product for your circuit and equipment protection needs. These branch circuit rated, 600v, 200,000a IR fuses offer exceptional protection in the smallest package of any UL class of fuses. Choose from the ultimate protection provided by our Low Peak LP-CC fuses, the time delay of our FNQ-R's for your control transformer and similar control applications or the fast acting protection of our KTK-R Limitron fuses for specialized circuits such as lighting protection
Manuals and Documentation
Features
- Provides 10X better current limitation to help prevent equipment damage caused by short circuit events
- 200 kA AC rms symmetrical interrupt rating complies with NEC section 110.9 for today's large capacity systems
- Fast acting fuse helps prevent equipment damage caused by short circuit events
- Rejection type fuse fits both standard and rejection style holders
- Ideal for critical industrial or commercial applications that have specific current limitation requirements
- Nickel plated bronze end caps
- Class CC rejection feature with appropriate fuse block, prevents inserting lesser rated supplementary fuse
| Manufacturer Part Number | KTK-R-8 |
| Brand | Bussmann |
| Manufacturer | Eaton |
| UPC | 051712420679 |
| Amperage Rating | 8 A |
| Material | Melamine Tube |
| Mounting Type | Holder |
| Series | KTK-R |
| Type | Current Limiting Fast Acting |
| Voltage Rating | 600 V |
| Alternative Part Number | 7614157 |
| Manufacturer Item Status | Active |
| Country | USA |
| Standards Approvals | UL Listed ,CSA Certified,CE Marked,RoHS Compliant |
| Application | Industrial Facilities and Factories, Safety and Security Systems, Isolated and In-Line Fuse Holders, Specialized Circuits and Branch Circuits Applications |
| Body Size | 13/32 in Dia x 1-1/2 in L |
| Body Type | Cylindrical |
| Class | CC |
| Element | Single |
| Indicating Non Indicating | Non-Indicating |
| Interrupt Rating | 200 kAIC |
| Rejection Non Rejection | Rejection |
| Terminal Type | Ferrule End |
