FG3125A05S01 C Series Fixed Pickup Molded Case Engine Generator Circuit Breaker, 600 V AC, 125 A, 14/15 kA Interrupt, 3 Poles, Thermal Magnetic Trip
- MFR:
- Eaton
- MFR #:
- FG3125A05S01
- UPC:
- 782116018543
- Item #:
- 579377
FG3125A05S01 C Series Fixed Pickup Molded Case Engine Generator Circuit Breaker, 600 V AC, 125 A, 14/15 kA Interrupt, 3 Poles, Thermal Magnetic Trip
- MFR #:
- FG3125A05S01
- UPC:
- 782116018543
- Item #:
- 579377
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$4,082.19
each
Experience the superior quality of the Eaton Series C Molded Case Circuit Breaker. The Series Ccircuit breakeris ideal forpanelboards,switchboards, motor control centers, and busway applications. Choose from a premier selection of trip units including thermal magnetic, electronic, and magnetic only switches. Available for systems up to 600 VAC or 250 VDC with current ratings up to 800A.
| Catalog Number | FG3125A05S01 |
| Manufacturer | Eaton |
| Brand | Eaton |
| Country of Origin | Dominican Republic |
| Made in USA | No |
| Application | Other |
| Current Rating | 125 A |
| Frame | F |
| Frequency Rating | 60 Hz |
| Interrupt Rating | 14 kAIC at 480 Vac|18 kAIC at 240 Vac |
| Number of Poles | 3 |
| Standard | IEC Rated,UL 489,UL Listed,CSA Std. C22.2 No. 5,IEC 947-2,CSA Certified |
| UPC | 782116018543 |
| GTIN | 00782116018543 |
| Item Type | Molded case circuit breaker |
| Trip Type | Fixed thermal, fixed magnetic |
| Voltage Rating | 600 Vac |
