APD2000W1 1-Relay Dimming Occupancy Sensor Switch, 24 VDC, Passive Infrared Sensor
- MFR:
- Hubbell
- MFR #:
- APD2000W1
- UPC:
- 783585427102
- Item #:
- 573442
APD2000W1 1-Relay Dimming Occupancy Sensor Switch, 24 VDC, Passive Infrared Sensor
- MFR #:
- APD2000W1
- UPC:
- 783585427102
- Item #:
- 573442
Availability
| Location | Available Qty |
|---|---|
| Available | 8 ea |
The Hubbell Dimming Wall Switch Sensor combines passive infrared (PIR) technology with the additional energy savings of 0 to 10 VAC dimming. The light level can be either predetermined or the sensor can be configured to remember the last dimming setting upon occupancy. With manual override ON/OFF and dimming control, the light level can be easily adjusted to a desired set point. The sensor features Hubbell patented Adaptive Technology, which continuously analyzes its environment and auto adjusts the sensitivity and timer based on environmental history, eliminating the need for manual adjustment. This helps provide true maintenance free "Install and Forget" operation. This series also feature selectable Automatic ON/OFF or Manual ON/Automatic OFF, or vacancy only operation modes and a built-in photocell for automatic daylight harvesting.
Manuals and Documentation
Features
- All digital, passive infrared sensor for excellent passive infrared long range motion detection
- No minimum load requirement
- Compatible with IEC 60929 standard ballasts/LED drivers
| Manufacturer Part Number | APD2000W1 |
| Brand | Hubbell Wiring Device-Kellems |
| Manufacturer | Hubbell |
| UPC | 783585427102 |
| Country Of Origin | CN |
| Color | White |
| Lamp Type | CFL/Fluorescent/Incandescent/LED |
| Material | Plastic |
| Mounting Type | Wall |
| Temperature Rating | -40 to 70 deg C |
| Type | 1-Relay Dimming |
| Voltage Rating | 24 V DC |
| Alternative Part Number | 13623781 |
| Manufacturer Item Status | Discontinued |
| Country | USA/Canada |
| Warranty | Limited |
| Standards Approvals | CSA Certified | cULus Listed | UL Listed |
| Application | Lighting Control and Indoor Dry Applications |
| Control Output | Manual On/Automatic Off/Automatic On/Automatic Off |
| Power Rating | 800/1800 |
| Sensor Type | Passive Infrared |
| Time Delay | 4 to 30 min |
