Standard Passive Infrared Technology requires a clear, unobstructed line of sight for detection, because it senses occupancy as movement of heat emitted from the body against the background space. A segmented Fresnel lens divides a coverage area into zones. Movement across zones is interpreted as occupancy. Excellent for small room control.

Manuals and Documentation
Catalog Number WS1020NGY
Manufacturer Hubbell Wiring Device-Kellems
Brand Hubbell Wiring Device - Kellems
Country of Origin Taiwan, Province Of China
Made in USA No
Application Dual Circuit
Color Gray
Connector Terminal Screws
Mounting Screw
Sensing Range 1000 Square Feet
Sensitivity Adjustable
Sensor Passive Infrared
Special Features 2-Circuit, With Night Light
Standard UL/CSA
Supply Voltage 120 AC
UPC 783585428130
GTIN 00783585428130
Item Type Manual/Auto
Environmental Conditions Indoor Dry Unless Protected by Additional Means
Operating Temperature 0 Degrees C to 40 Degrees C
