Limit switch, 9007, 9007FT foundry standard, spring return, CW+CCW, 1/2" NPT
- MFR:
- Telemecanique Sensors
- MFR #:
- 9007FTSB2
- UPC:
- 785901119333
- Item #:
- 530344
Limit switch, 9007, 9007FT foundry standard, spring return, CW+CCW, 1/2" NPT
- MFR #:
- 9007FTSB2
- UPC:
- 785901119333
- Item #:
- 530344
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$1,355.45
each
9007FT foundry limit switch - standard - spring return - CW+CCW - 1/2" NPT
Manuals and Documentation
| Catalog Number | 9007FTSB2 |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Unknown |
| Made in USA | No |
| Action | From left or right;CW and CCW;Lateral approach;Snap action |
| Actuator | Spring return without operating lever |
| Amperage Rating | 20 |
| Application | Standard foundry switch |
| Connection | Screw-clamp terminals AWG 22...AWG 12 |
| Contact Configuration | Form Z |
| Enclosure | NEMA 1 NEMA TYPE 250-NEMA 2 NEMA TYPE 250-NEMA 4 NEMA TYPE 250-NEMA 12 NEMA TYPE 250-NEMA 13 NEMA TYPE 250 |
| Mounting | By The Body |
| Number of Poles | 1 |
| Special Features | 2 STAGES SEQUENTIAL,FIXED |
| Standard | 10 GN 10-55 HZ)IEC 60068-2-6,30 GN 9 MS IEC 60068-2-27,IP67 IEC 60529,CLASS 0 IEC 61140 |
| UPC | 785901119333 |
| GTIN | 03389119056977 |
| Item Type | Limit switch |
| Size | 3.41 |
| Operating Temperature | -10-185 A Degrees F |
