JGH3100FAG Type JGH Molded Case Circuit Breaker, 600 V AC/250 V DC, 100 A, 25/65/100 kA Interrupt, 3 Poles, Thermal Magnetic Trip
- MFR:
- Eaton
- MFR #:
- JGH3100FAG
- UPC:
- 782113963402
- Item #:
- 526248
JGH3100FAG Type JGH Molded Case Circuit Breaker, 600 V AC/250 V DC, 100 A, 25/65/100 kA Interrupt, 3 Poles, Thermal Magnetic Trip
- MFR #:
- JGH3100FAG
- UPC:
- 782113963402
- Item #:
- 526248
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$11,350.46
each
The Eaton Series G Molded Case Circuit Breaker provides users with unparalleled performance and convenience. A patented contact design features high-speed blow-open action, resulting in superiorcircuit breakerperformance. This globally-rated platform offers users high interruption ratings in a compact footprint with ease of in-field configuration applicable to a wide variety of industry and regional requirements. Choose from a selection of thermal magnetic and electronic trip units, available in current ratings that range from 15A to 2500A with voltages up to 690 VAC.
Manuals and Documentation
| Catalog Number | JGH3100FAG |
| Manufacturer | Eaton |
| Brand | Eaton |
| Country of Origin | Dominican Republic |
| Made in USA | No |
| Application | Elec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - Other |
| Current Rating | 100 A |
| Frame | JG |
| Frequency Rating | 50/60 Hz |
| Interrupt Rating | 25 kAIC at 600 Vac|65 kAIC at 480 Vac|100 kAIC at 240 Vac |
| Number of Poles | 3 |
| Standard | IEC Rated,UL Listed,CSA Certified,CE Marked |
| UPC | 782113963402 |
| GTIN | 00782113963402 |
| Item Type | Molded case circuit breaker |
| Trip Type | Fixed thermal, adjustable magnetic |
| Voltage Rating | 600 Vac, 250 Vdc |
