8536SEH1V03 Type S Magnetic Starter, 220 V AC at 50 Hz/240 V AC at 60 Hz V Coil, 3 Poles, NEMA 3R Enclosure
- MFR:
- Schneider Electric
- MFR #:
- 8536SEH1V03
- UPC:
- 785901823278
- Item #:
- 513486
8536SEH1V03 Type S Magnetic Starter, 220 V AC at 50 Hz/240 V AC at 60 Hz V Coil, 3 Poles, NEMA 3R Enclosure
- MFR #:
- 8536SEH1V03
- UPC:
- 785901823278
- Item #:
- 513486
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
Type S NEMA motor starters are used for full voltage starting and stopping of AC squirrel cage motors. Type S motor starters have ratings up to 810 amperes. This 3 pole NEMA Size 3 non-reversing starter has a 90 ampere rating. This NEMA Size 3 motor starter has 3 phase ratings of 25 HP at 200 VAC, 30 HP at 230 VAC and 50 HP at 460 and 575 VAC. This non-reversing NEMA motor starter has a melting alloy type overload relay that uses Type CC thermal units to sense over current conditions. This NEMA starter has a 5 kA maximum SCCR (Short Circuit Current Rating) per UL508A when protected by an appropriate circuit breaker or fuse. Type S motor starters are available with replaceable coils in a wide variety of voltages. This starter has a 220/240 VAC 50/60 Hz operating coil wired for common control. A painted sheet steel NEMA 3R rainproof and sleet resistant enclosure for outdoor use is used to protect this starter. Enclosure is 25.28 inches tall, 12.84 inches wide and 8.63 inches deep. A wide variety of accessories are available for Type S starters. Type S non-reversing NEMA motor starters are UL listed and CSA certified.
Manuals and Documentation
| Catalog Number | 8536SEH1V03 |
| Manufacturer | Schneider Electric |
| Brand | SQUARE D |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Mexico |
| Made in USA | No |
| UPC | 785901823278 |
| GTIN | 00785901823278 |
