1602A3R Elastimold Loadbreak Feed Through Insert, 15 kV, 200 A, For Use With Loadbreak System, -40 to 65 deg C, 4 in Center to Center Spacing, EPDM Rubber
- MFR:
- ABB - Installation Products
- MFR #:
- 1602A3R
- UPC:
- 783786469468
- Item #:
- 496346
1602A3R Elastimold Loadbreak Feed Through Insert, 15 kV, 200 A, For Use With Loadbreak System, -40 to 65 deg C, 4 in Center to Center Spacing, EPDM Rubber
- MFR #:
- 1602A3R
- UPC:
- 783786469468
- Item #:
- 496346
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$1,003.70
each
| Catalog Number | 1602A3R |
| Manufacturer | ABB - Installation Products |
| Brand | ELASTIMOLD |
| Country of Origin | United States |
| Made in USA | Yes |
| Application | Designed for use as an apparatus bushing interface and provide extra tap connection |
| Material | EPDM Rubber |
| Special Features | 15kV, 200 Amp Loadbreak Rated. Transform radial feed transformer into loop-feed unit. Provide extra tap for elbow arrester connection. Peroxide-cured insulation and jacket. Provision for groundwire connection. Fully rotatable for 360 degree positioning. Includes bail assembly to secure feed-thru insert to bushing well |
| Standard | ANSI/IEEE 386 |
| UPC | 783786469468 |
| GTIN | 00783786469468 |
| Item Type | Feed-Thru Insert |
| Size | 10.66 inch (270.8 mm) Length, 4.00 inch (101.6 mm) Center to Center, 7.00 inch (177.8 mm) wide |
| Temperature Rating | -40 to +65 C |
