nVent HOFFMAN

A72XM3418FTCG A28M1 1-Door Heavy Duty Disconnect Enclosure With Panel, 72.12 in L x 34-1/4 in W x 18.12 in D, NEMA 12/IP55 NEMA Rating, Steel

MFR:
nVent
MFR #:
A72XM3418FTCG
UPC:
783510256746
Item #:
466842

Availability

Location Available Qty
Available Available to Order
$7,718.73 each

Simple, heavy-duty and cost-effective, this disconnect enclosure can be ordered with one to six doors to fit a range of applications.

Manuals and Documentation

Features

  • Seams continuously welded and ground smooth
  • Body stiffeners in larger enclosures for extra rigidity
  • Body flange trough excludes liquids and contaminants
  • Heavy-duty lifting eyes anchor into reinforced top
  • Removable centerposts permit easy panel installation
  • Concealed, easy-to-remove hinges
  • Heavy-duty 3-point latching mechanism operated by padlocking handle on all doors
  • Panel supports
  • Data pocket is high-impact thermoplastic
  • Oil-resistant gasket
Manufacturer Part Number A72XM3418FTCG
Brand nVent HOFFMAN
Manufacturer nVent
UPC 783510256746
Country Of Origin MX
Color Gray
Depth 18.12 in
Finish Polyester Powder Painted
Length 72.12 in
Material Steel
Mounting Type Freestanding
Series A28M1
Type 1-Door Heavy Duty
Width 34-1/4 in
Cover Type Concealed Hinged
Alternative Part Number 11761754
Manufacturer Item Status Active
Country USA/Canada
Standards Approvals cUL Listed per CSA C22.2 File No. 94 File No. E61997 | IEC 60529 | UL 508A File No. E61997 | REACH Compliant
Application For simple, heavy duty and cost effective, this disconnect enclosure can be ordered with one to six doors to fit a range of applications
Includes Door Hardware
Lock 3-Point Latch/Padlock Handle
Nema Rating NEMA 12/IP55
Panel Size 60 x 27-3/4 in
