10250T452 Heavy Duty Oiltight/Watertight Joystick Operator, 30.5 mm, 3NO-4NC Contact, 2 Positions, Black
- MFR:
- Eaton
- MFR #:
- 10250T452
- UPC:
- 782113125459
- Item #:
- 45762
10250T452 Heavy Duty Oiltight/Watertight Joystick Operator, 30.5 mm, 3NO-4NC Contact, 2 Positions, Black
- MFR #:
- 10250T452
- UPC:
- 782113125459
- Item #:
- 45762
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$696.37
each
Eaton's 10250T line of 30.5 mm pushbuttons features a heavy-duty zinc die cast construction. Reliability nibs improve contact reliability even under dry circuit and fine dust conditions. In addition, drainage holes prevent the buildup of liquid inside the operator, which can prevent operation in freezing environments.
Manuals and Documentation
Features
- The device mounts in the standard 30.5 mm mounting hole
- Allow sufficient panel space for lever movement
- The maximum travel of the knob operator (full up to full down) is 2.2 in (24 deg) momentary
- 2-1/2 in (30 deg) maintained, but ample space for lever operation must be allowed
- These operators are field convertible from momentary to maintained operation or vice versa
- The use of NC contacts is preferred because they provide positive drive contact opening and a direct relationship between lever movement and affected terminal, up movement affects the top terminals
- Momentary up and down
- Without overcurrent latch
| Manufacturer Part Number | 10250T452 |
| Brand | EATON |
| Manufacturer | Eaton |
| UPC | 782113125459 |
| Country Of Origin | DO |
| Color | Black |
| Enclosure Type | NEMA 3/3R/4/4X/12/13 |
| Series | 10250T |
| Temperature Rating | 140 deg F |
| Type | Heavy Duty Oiltight/Watertight |
| Size | 30.5 mm |
| Alternative Part Number | 7337275 |
| Manufacturer Item Status | Active |
| Country | USA/Canada |
| Standards Approvals | CSA Certified,UL Listed,CE Marked |
| Application | Automation and Logic Control Equipment, Electrical Assemblies, Panels and EOEMs Applications |
| Contact Configuration | 3NO-4NC |
| Contact Mode | Momentary |
| Number Of Positions | 2 |
