Discontinued
9007MS02S0112 9007MS/ML Fixed Miniature Potted Plunger Actuated Limit Switch, 120/240 VAC, 28 VDC, 3/5/6 A, Parallel Roller Plunger Spring Return Actuator, 1NO-1NC Contact, 1 Poles
- MFR:
- Schneider Electric
- MFR #:
- 9007MS02S0112
- UPC:
- 785901753926
- Item #:
- 446778
Discontinued
9007MS02S0112 9007MS/ML Fixed Miniature Potted Plunger Actuated Limit Switch, 120/240 VAC, 28 VDC, 3/5/6 A, Parallel Roller Plunger Spring Return Actuator, 1NO-1NC Contact, 1 Poles
- MFR #:
- 9007MS02S0112
- UPC:
- 785901753926
- Item #:
- 446778
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
9007MS limit switch - parallel roller plunger - 7/8" AC DC 3' bottom cable
Manuals and Documentation
| Catalog Number | 9007MS02S0112 |
| Manufacturer | Schneider Electric |
| Brand | Square D |
| Warranty Description | Contractual Warranty: 18 months |
| Country of Origin | Mexico |
| Made in USA | No |
| Action | By 30 Degrees cam;Lateral approach, 2 directions;Snap action |
| Actuator | Spring return parallel roller plunger steel - |
| Amperage Rating | 6 |
| Application | 9007MS/ML,MINIATURE POTTED,PLUNGER HEAD |
| Connection | Pigtail connector 7/8"-16 mini 4 pins bottom |
| Contact Configuration | Form C;NC-NO |
| Enclosure | NEMA 1 NEMA TYPE 250-NEMA 2 NEMA TYPE 250-NEMA 4 NEMA TYPE 250-NEMA 6 NEMA TYPE 250-NEMA 6P NEMA TYPE 250 |
| Mounting | By The Body |
| Number of Poles | 1 |
| Operating Cycles | 100000 CYCLES |
| Special Features | FIXED,METAL |
| Standard | 10 GN 75-1200 HZ)IEC 60068-2-6,35 GN 9 MS IEC 60068-2-27,IP67 IEC 60529,LR 25490 CLASS 32 11 03-E78403,UL-CE-CSA |
| UPC | 785901753926 |
| GTIN | 00785901753926 |
| Item Type | Limit switch |
| Size | 0.62 |
| Operating Temperature | -40-220 A Degrees F |
| Voltage Rating | 5 A 28 V DC-3 A 240 V AC-6 A 120 V AC |
