Limit switch, L100/300, L300 foundry 2 contacts, spring return, CW+CCW, 1/2" NPT
- MFR:
- Telemecanique Sensors
- MFR #:
- L300WNC2M18
- UPC:
- 785901079040
- Item #:
- 445979
Limit switch, L100/300, L300 foundry 2 contacts, spring return, CW+CCW, 1/2" NPT
- MFR #:
- L300WNC2M18
- UPC:
- 785901079040
- Item #:
- 445979
Availability
| Location | Available Qty |
|---|---|
| Available | Available to Order |
$790.53
each
L300 foundry limit switch - 2 contacts - spring return - CW+CCW - 1/2" NPT
Manuals and Documentation
| Catalog Number | L300WNC2M18 |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Czech Republic |
| Made in USA | No |
| Action | From left or right;CW and CCW;Lateral approach;Slow-break, break before make |
| Actuator | spring return without operating lever |
| Amperage Rating | 20 |
| Application | Foundry switch |
| Connection | Screw-clamp terminals AWG 22...AWG 12 |
| Contact Configuration | 2 NC;Form YY |
| Enclosure | NEMA 1 NEMA TYPE 250-NEMA 2 NEMA TYPE 250-NEMA 4 NEMA TYPE 250-NEMA 12 NEMA TYPE 250-NEMA 13 NEMA TYPE 250 |
| Mounting | By The Body |
| Number of Poles | 2 |
| Special Features | FIXED,NEUTRAL POSITION |
| Standard | 10 GN 10-55 HZ)IEC 60068-2-6,30 GN 9 MS IEC 60068-2-27,IP67 IEC 60529,CLASS 0 IEC 61140 |
| UPC | 785901079040 |
| GTIN | 00785901079040 |
| Item Type | Limit switch |
| Size | 2.03 IN,2.25 IN,4.95-4.95 IN |
| Operating Temperature | -10-185 A Degrees F |
