Discontinued
Hubbell Wiring Device - Kellems

HBL5262ALSA Specification Grade Standard Decorator Duplex Tvss Receptacle, 28 VDC, 30 A, 60 Hz, 1 Phase

MFR:
Hubbell Wiring Device-Kellems
MFR #:
HBL5262ALSA
UPC:
783585436081
Item #:
43565

Availability

Location Available Qty
Available Available to Order

HBL Extra Heavy Duty Max Industrial Series - Hubbells commitment to quality continually reinforces a philosophy of unrivaled performance. No Hubbell device exemplifies this philosophy more than the HBL5262. While all Hubbell receptacles are designed and manufactured to withstand even the harshest environments, none match the total performance of the HBL5262. Whether in a factory, office building or school, the Hubbell HBL5262 is the receptacle of choice when people are depending on the safety and reliability of a receptacle. The safest, most reliable design for a low resistance flow of fault currents. Oversized bell" shaped ground contacts, along with nickel plated steel retaining shields, help minimize damage to the grounding system during abrupt pullout.

Manuals and Documentation
Catalog Number HBL5262ALSA
Manufacturer Hubbell Wiring Device-Kellems
Brand Hubbell Wiring Device - Kellems
Country of Origin China
Made in USA No
Amperage Rating 15
Application Decorator Duplex with Light and Alarm
Connection Terminal Screws
Frequency Rating 60 HZ
Material Composite
Mounting Screw
Phase 1
Response Time 5
Special Features Standard Product
Standard CSA Certified to Specification C22.2 No. 42;Listed to UL Standards 498;UL Listed File E2186
UPC 783585436081
GTIN 00783585436081
Item Type Duplex
Size Standard
Environmental Conditions Indoor Dry Unless Protected By Additional Means
Operating Temperature 32 Deg F to 140 Deg F (0 Deg C to 60 Deg C)
Type of Indicators LED and Audible Alarm
Voltage Rating 125
